Engineered for versatile and effective soil compaction on medium production site work, the SV414D smooth drum vibratory compactor is a dependable choice. Weighing just under 8 tons with a 67-inch compaction width, this roller efficiently compacts both cohesive soils (like clay and silt) and granular materials or rockfill (including sand, gravel, and crushed rock). It is ideal for applications like roadway and parking lot subbase, and commercial site prep. Powered by a dependable 74 HP Cummins diesel engine, the SV414D delivers consistent power and operational efficiency. Its user-selectable traction control system ensures confident operation on slopes of up to approximately 32.2 degrees (63% grade), proving invaluable for challenging embankments, ramps, and various sloped site preparations.
Embodying SAKAI’s enduring legacy of reliability, durability, and ease of use, the SV414D offers consistent, dependable performance on the job site. Operators will find its intuitive control layout highly responsive, featuring traditional analog switches and knobs that provide precise command and foster a reduced learning curve for new operators, all without the complexities of modern, failure-prone touchscreens. Built with a heavy-duty center hitch design, this SAKAI soil compactor is engineered for maximum uptime and operator confidence, making it a powerful, user-friendly, and consistently productive solution for quality soil compaction.
Features & Benefits:
- Traction control system
- High centrifugal force outputs
- Several amplitude and frequency setting combinations
- All vibration controls at instrument panel
- Heavy duty center hitch design
- Superior shock isolation system
- Independent drum vibration
- Standard safety equipment: ROPS, retractable seat belt, horn, backup alarm, operator deck hand rails, electric parking brake w/ interlock, & foot brake
Applications:
- Medium production soil compaction jobs
- Cohesive soils (clay, silt)
- Granular soils or rockfill (sand, gravel, crushed rock)
- Roadway and parking lot subbase
- Embankments
- Building foundations
- Commercial and industrial tracts
- Road widening
- Subgrade & subbase
Specifications
| DRUM |
| Type |
Smooth Single Drum |
| Size (w x d) |
67X48 ins | 1,700X1,220 mm |
| OPERATING |
| Weight |
15,765 lbs | 7,150 kg |
| Gradability |
63% |
| VIBRATION |
| Frequency |
2,280 vpm/1,800 vpm | 38 Hz/30 Hz |
| Centrifugal Force |
20,905 lbs/26,525 lbs | 93 kN/118 kN |
| Nominal Amplitude |
0.03 ins/.061 ins | 0.75 mm/1.55 mm |
| ENGINE |
| Make & Model |
Cummins QSF 2.8 (EPA-Tier 4) |
| Horsepower |
74HP@ 2400 rpm | 55kW @ 2400 min-1 |
| BRAKING |
| Systems |
Hydrostatic Service Brake + SAHR + Combined Footbrake |
