SV544DF Padfoot Shell Compactor

HomeSoil Compactors84" (12 ton)SV544DF Padfoot Shell Compactor

RELIABLE. EASY-TO-USE. DURABLE.

  • 84"
  • 27,955 lbs
  • 130 HP Cummins

The innovatively designed SV544 is suitable for medium to large soil compaction jobs, sitework, dirtwork, earthwork, subgrades, subbases, and civil construction site prep.

Manual Traction Control

  • High traction capability ensures compaction in both forward and reverse — even on jobs with soft ground, slopes or rough terrains.
  • Manual traction control allows forward slope and reverse slope operation.

Manual Vehicle Speed Control

  • Selective travel mode (2.5 – 6.2 mph)

Vibration System

  • There are 2 range of vibration, high amplitude and low amplitude.
  • Reaches target density in fewer roller passes.
  • Achieves uniform compaction throughout lift thickness.

Long Lasting Drum Isolator System

  • Sakai’s unique drum mounting system extends the life of the drum isolators.
  • Patented drum vibration isolation system and floating deck keep the operator free from vibration.
  • Durable, high quality components such as hydraulics, drum and center-pin hitch assure longer life and lower maintenance costs.

Standard Safety Equipment

  • ROPS
  • Sakai proprietary emergency brake pedal which kills the engine and stops the machine instantly
  • Retractable seat belt
  • Horn and backup alarm
  • Operator deck hand rails
  • Electric parking brake w/ interlock

Specifications

DRUM
Type Smooth Drum w/ Padfoot Shell Kit
Size (w x d) 84″ x 67″ | 2,130 x 1,708 mm
OPERATING
Weight  27,955 lbs | 12,680 kg
Gradability 63%
VIBRATION
Frequency 2,000 vpm/1,730 vpm | 33.3 Hz/28.8 Hz
Centrifugal Force 32,820 lbs/57,325 lbs | 146 kN/255 kN
Nominal Amplitude 0.024″/ 0.057″ | 0.62 mm/1.45 mm
ENGINE
Make & Model Cummins QSF 3.8 (EPA-Tier 4)
Horsepower 130 HP@ 2200 rpm | 97 kW @ 2200 min-1
BRAKING
Systems Hydrostatic Service Brake + SAHR + Combined Footbrake

OPTIONS
